Wheel
K865ZGRNB
Wheel Material : Rubber
Wheel Center : Nylon
Wheel Bearing : Precision Ball Bearing
Housing Type : Plate Swivel
Housing Bearing : Double Bearing Structure
Housing Coat : Zinc
Stopper : Double Break
Specification
| Wheel Size (D) | 80 mm | 100 mm | 125 mm |
| Wheel Width (W) (mm) | 32 | 32 | 35 |
| Mounting Height (H) (mm) | 105 | 128 | 156 |
| Mounting Base (A x B) (mm) | 105 x 80 | 105 x 80 | 105 x 80 |
| Mounting Dimension (X x Y) (mm) | 77 x 56 | 77 x 56 | 77 x 56 |
| Plate Hole (P) (mm) | 9.5 | 9.5 | 9.5 |
| Turning Radius (R) (mm) | 102 | 102 | 102 |
| Load Capacity (kgs./wheel) | 70 | 90 | 110 |
