Wheel
K420ZANAN
Wheel Material : Nylon
Wheel Center : Nylon
Wheel Bearing : Bore Hole
Housing Type : Screw-in
Housing Bearing : Double Bearing Structure
Housing Coat : Zinc
Stopper : none
Specification
| Wheel Size (D) | 40 mm | 50 mm | 65 mm | 75 mm |
| Wheel Width (W) (mm) | 23 | 23 | 23 | 23 |
| Mounting Height (H) (mm) | 58 | 67 | 84 | 99 |
| Threaded Stem Length (T) (mm) | 15 | 15 | 15 | 25 |
| Threaded Stem Size (inch) | 1/2 NF | 1/2 NF | 1/2 NF | 1/2 NF |
| Hexagon Size (mm) | 21 | 21 | 21 | 21 |
| Turning Radius (R) (mm) | 38 | 44 | 52 | 65 |
| Load Capacity (kgs./wheel) | 30 | 40 | 45 | 50 |
